Acoustic
High tone quality capable of reproducing subtle nuances of acoustic instruments
Intelligent
High-performance DSP effects and EQ driven by a powerful new processor
Xpression
Wide range of built-in tones with unique and powerful expression capabilities
Specifications:
Keyboard |
61 standard size keys
Touch Response: Sensitivity 3 types, Off |
---|---|
Maximum Polyphony |
48 notes (24 for certain tones) |
Tones |
Built-in Tones: 600
Functions: Layer, Split, Piano/Organ button |
Reverb |
1 to 20, Off |
Chorus |
1 to 10, Tone |
Metronome |
Beats per Measure: 0 to 9
Tempo Range: 20 to 255 |
Song Bank |
Demo Song: 1
Built-in Songs: 160
User Songs: 10*
User-recorded songs: 6*
* Maximum capacity per song: Approximately 320 kilobytes |
Step Up Lesson |
Lessons: 3 (Listen, Watch, Remember), Easy Mode
Lesson Part: L, R, LR
Functions: Repeat, Voice Fingering Guide, Note Guide, Performance Evaluation |
Auto Accompaniment |
Built-in Rhythms: 195
User Rhythms: 10*
* Maximum capacity per rhythm: Approximately 64 kilobytes |
Chord Book Function |
Chord guide |
Registration |
32 (4 setups x 8 banks) |
Recorder |
Real-time recording, playback
Keyboard Play: 5 songs, 6 tracks
Playing Along with a Built-in Songs: 1 song (L, R, LR)
Memory Capacity: Approximately 40,000 notes (1 song) |
Other Functions |
Transpose: 1 octaves (-12 to +12 semitones)
Octave Shift: Upper 1/Upper 2/Lower, 3 octaves
Tuning: A4 = 415.5 to 465.9 Hz (Initial Default: 440.0 Hz)
Preset Scales: 17
Music Preset: 310
One Touch Preset: 195
Auto Harmonize: 12 types
Arpeggiator: 100 types |
MIDI |
16 multi-timbre received, GM Level 1 standard |
Musical Information Function |
Tone, Rhythm, Song Bank numbers and names, staff notation, fingering, pedal operation, tempo, measure and beat number, chord name, etc. |
Inputs/Outputs |
USB port: TYPE B
PEDAL jack: Standard jack (sustain, sostenuto, soft, rhythm)
Phones/Output jack: Stereo standard jack/Output Impedance 167?, Output Voltage 4.5V (RMS) MAX
Audio In jack: Stereo mini jack/Input Impedance 10k?, Input Sensitivity 200mV |
Power Jack |
DC 9.5V |
Power Supply |
2-way
Batteries: 6 AA-size alkaline batteries
Battery Life: Approximately 3 hours continuous operation on alkaline batteries
AC Adaptor: AD-E95100L
Auto Power Off: Approximately 30 minutes after last operation; Can be disabled. |
Speakers |
12cm x 2 (Output: 2.5W + 2.5W) |
Power Consumption |
7.5 W |
Dimensions |
W 94.8 x D 35.0 x H 10.9 cm |
Weight |
Approximately 4.3 kg (without batteries) |
Included Accessories |
Music stand |
