Keyboard
61 standard size keys
Touch Response: Sensitivity 3 types, Off
Maximum Polyphony
64 notes (32 for certain tones)
Tones
Preset Tones: 800 ( 43 Indian & 57 SFX)
User Tones: 100
Other: Layer, split (configurable split point, lower point, chord point settings)
System Effects
Reverb: 32 types, Off
Chorus: 16 types, Tones
Delay: 20 types, Tones
DSP: 100 types (Can be applied to user tones using DSP editing.), DSP tones
Master Effects
Equalizer (10 presets)
4-band User Equalizer
External Input Effects
Center cancel (vocal cut) for input from the Audio In jack
Metronome
Beat: 0 (accented tone off), 1 to 16
Tempo: Tempo value: 20 to 255
Song Bank
Built-in Songs: 30
User-recorded Songs: 10
USB Memory Songs: Playback of standard MIDI files (SMF format 0/1), CASIO MIDI files (CMF format) on a USB flash drive is supported.
USB Audio Playback
Playback of audio files on a USB flash drive is supported.
Supported File Formats: WAV format, 44.1 kHz 16 bit
Other Functions: Center Cancel (Vocal Cut)
Auto Accompaniment
Built-in Rhythms: 250 ( 39 Indian)
User Rhythms: 100
One Touch Presets
Music Presets
310 (With chord progressions)
Phrase Pads
Number of Pads: 4
User Phrases: 100 (4 phrases x 25 pads)
Editing Mode: Copy, delete, phrase editing
Mixer function
Affected Parts: Sound source parts, microphone input part
Parameters: Part on/off, volume, pan, reverb send, chorus send, delay send
Registration
Maximum 128 setups (8 setups x 16 banks), registration sequence
Tone Editing
Preset tone editing, DSP editing
Memory for storage of edited tones (up to 100)
Rhythm Editing
New rhythm creation, rhythm editing
Memory for storage of created/edited rhythms (up to 100)
MIDI Recorder
Real-time recording, playback
Keyboard Performance Recording: 10 songs, 17 tracks (1 system track, 16 solo tracks)
Memory Capacity: Approximately 40,000 notes (per song)
Editing Mode: Song editing, track editing, event editing, step input
Other Functions: Overdubbing, punch-in recording
Pedals
Sustain, sostenuto, soft, rhythm/song, expression
Controllers
Pitch bend wheel, SUSTAIN button, PORTAMENTO button, MODULATION/ ASSIGNABLE button
Other Functions
Transpose: 1 octaves (-12 to 0 to +12 semitones)
Octave Shift: Upper 1/Upper 2/Lower 1/Lower 2, 3 octaves
Tuning: A4 = 415.5 to 465.9 Hz (Initial Default: 440.0 Hz)
Part coarse tune: For each keyboard part, 2 octaves (-24 to 0 to +24 semitones)
Part fine tune: For each keyboard part, 99 cents
Scales: 17 preset scales, scale fine tuning
Auto Harmonize: 12 types
Arpeggiator: 150 types
MIDI
16ch multi-timbre received, GM Level 1 standard
Inputs/Outputs
USB Flash Drive Port: Type A
USB Port: Type B
Pedal 1 Jack: Standard jack
Pedal 2, Expression Jack: Standard jack
Headphones Jack: Stereo standard jack
Audio Input Jack: Stereo mini jack/Input impedance 9 k?, Input sensitivity 200 mV
Line Out Jack: Standard jacks x 2/Output impedance 2.3 k?, Output voltage 1.9 V (RMS) MAX
Microphone Input Jack: Standard jack (Connect a dynamic microphone.)/ Input impedance 3 k?, Input sensitivity 10 mV
Power Supply
AC adaptor only
AC Adaptor: AD-E24250LW
Auto Power Off: Approximately 30 minutes after last operation; Can be disabled.
Speakers
10cm x 2 (Output: 15W + 15W)
Dimensions
W 94.8 x D 38.4 x H 11.6 cm
Weight
Approximately 7.0 kg
Included Accessories
Music stand, AC adaptor
