Versatile and portable, the new CM-30 CUBE Monitor delivers 30 watts of audio punch through a rugged, high-quality 6.5" coaxial 2-way speaker with stereo preamp. The CM-30 is ideal for home-studio and wide-ranging monitoring applications, but it can be used for live monitoring onstage as well.
|
|
|
|
|---|---|---|
Convenient front-mounted control w/ 2-band EQSculpt your sound with the CM-30’s onboard 2-band equalizer. Dedicated knobs are provided for adjusting low and high frequencies. As with all other controls, the equalizer knobs are conveniently located on the front panel for quick access. |
Connectivity OptionsEach CM-30 is equipped with three input channels, with one XLR input for mic/line, and two additional Aux inputs that support RCA pin (L, R) and stereo mini-phone connectors. So with one CM-30 you get four stereo inputs and one mono input. The Stereo Link function allows two CM-30s to be linked for true stereo output, which enables a total of eight stereo inputs, and two mono mic/line ins. The CM-30 offers more than enough inputs to simultaneously connect a microphone, a keyboard, a rhythm machine, and a CD player, or to function as a mini PA rig. |
Rugged, Compact, and VersatileLike all members of the CUBE family, the CM-30 is a breeze to transport. From gig to gig, session to session, this amp travels light and performs big. It’s built to withstand the rigors of the road, thanks to its metal grill cover and protective corner covers. While the CM-30 is well suited for home studio and monitoring applications, it can be used for live monitoring onstage. |
| Rated Power Output | 30 W |
| Nominal Input Level (1kHz) | Channel 1(Mic/Line): -50 to -20 dBu Channel 2, 3 (Line): -20 dBu AUX IN 1, 2: -10 dBu Stereo Link Input: -10dBu |
| Nominal Output Level | Stereo Link Out L, R: -10 dBu |
| Speaker | 16 cm (6.5 inches) + Tweeter (Coaxial 2-Way) |
| Controls | Channel 1 (Mic/Line) Volume Knob Channel 2, 3 Volume Knobs Stereo Phones Level Knob Equalizer: Low Knob, High Knob Volume Knob Power Switch |
| Connectors | Channel 1 Input Jack (XLR type, 1/4" phone type) Channel 2, 3 Input Jack L (mono)(1/4" phone type) Channel 2, 3 Input Jack R (1/4" phone type) Aux In 1 Jack (RCA phono type) Aux In 2 Jack (Stereo miniature phone type) Stereo Link Out Jacks L, R (1/4" phone type) Stereo Link In Jack (1/4" phone type) Stereo Phones Jack (Stereo 1/4" phone type) |
| Power Supply | AC 117V, 230V, 240V |
| Power Consumption | 32 W |
