- Sound Generator
- Maximum Polyphony
- 64 voices
- Tones
- Tones: 601
Drum Sets: 9 - Tone Effects
- Reverb: 10 types
Chorus: 8 types - Keyboard
- Keyboard
- 61 keys (with velocity)
- Touch Sensitivity
- Key Touch: 3 types, fixed touch
- Speaker System
- Speakers
- Speakers: 12 cm (4-3/4 inches) x 2
- Rated Power Output
- 2.5 W x 2
- Arranger
- Styles
- Preset: 207 styles
- Tempo
- 5--280
- One Touch Setting
- 4 settings/style
- Quick Memory
- 4 memories
*Registered memories will be lost when the power turns off. - Controls
- START/STOP, INTRO/ENDING, FADE IN/OUT, FILL A, FILL B, CHORD, SYNC
- Songs
- Internal Songs
- 140 song
- Recorder
- 1 song
*The recorded song will be lost when the power turns off. - Convenient Functions
- Convenient Functions
- Metronome (Adjustable Tempo/Beat)
Transpose (Keyboard: in semitones)
Dual
Split (Split point adjustable)
Lesson
Speaker Auto Mute
Auto Off - Other
- Connectors
- PHONES/OUTPUT jack: stereo 1/4-inch phone type
AUX IN jack: stereo 1/4-inch phone type
MIC INPUT jack: 1/4-inch TRS phone type
PEDAL jack: 1/4-inch phone type
USB COMPUTER port: USB B
DC IN jack - Display
- Custom LCD
- Power Supply
- AC adaptor or Alkaline battery (AA, LR6) x 6
*Carbon-zinc batteries cannot be used. - Battery Life for Continuous Use
- Alkaline batteries (AA, LR6): Approximately 3 hours
*Differs depending on the conditions of use. - Power Consumption
- 10 W (When using the included AC adaptor)
- Accessories
- Owner's manual
Leaflet "USING THE UNIT SAFELY"
AC adaptor
Music rest - Options (sold separately)
- Pedal switch: DP series
- Size and Weight
- Width
- With music rest:
947 mm
37-5/16 inches
Without music rest:
947 mm
37-5/16 inches - Depth
- With music rest:
420 mm
16-9/16 inches
Without music rest:
317 mm
12-1/2 inches - Height
- With music rest:
275 mm
10-7/8 inches
Without music rest:
100 mm
3-15/16 inches - Weight (excluding AC adaptor and music rest)
- 3.9 kg
8 lbs 10 oz
