- Keyboard
- Keyboard
- 61 keys (with velocity)
- Sound Generator
- Maximum Polyphony
- 128 voices
- Parts
- 16 parts
- Wave Memory
- 64 MB
- Tones
- Tones: 391 + 256 (GM2) Drum Sets: 9 (GM2)
- Effects
- Reverb: 10 types Chorus: 8 types
- Transpose
- -12+12 (in semitones)
- Octave
- -1+1
- Arranger
- Tempo
- 30280
- Styles
- 253 styles
- One Touch Setting
- 4 settings/styles
- Controls
- START/STOP, SYNC START, INTRO/ENDING, FILL A, FILL B, FADE, CHORD
- Metronome
- Beat
- 0, 29
- Song
- Internal Songs
- 140 songs
- Recording
- 10 songs
- Other
- Rated Power Output
- 3 W + 3 W
- Speakers
- 10 cm x 2
- Controllers
- Pitch bend wheel
- Display
- Custom LCD
- Connectors
- PHONES jack: Stereo 1/4-inch phone type OUTPUT (L/MONO, R) jacks: 1/4-inch phone type SUSTAIN jack: 1/4-inch phone type USB Computer port: USB B type DC IN jack
- Power Supply
- AC adaptor or Alkaline battery (AA, LR6) x 6 *Carbon-zinc batteries cannot be used.
- Battery Life for Continuous Use
- Alkaline batteries (AA, LR6): Approximately 6.5 hours *This figure will vary depending on the actual conditions of use.
- Current Draw
- 1 A
- Accessories
- Owner's Manual Leaflet "USING THE UNIT SAFELY" AC adaptor Music rest
- Options (sold separately)
- Pedal switch: DP series
- Size and Weight
- Width
- 956 mm 37-11/16 inches
- Depth
- 360 mm 14-3/16 inches
- Height
- 133 mm 5-1/4 inches
- Weight (excluding AC adaptor)
- 5.0 kg 11 lbs 1 oz
